WHAT YOU'LL LEARN
  • how to use advanced search filter in Headless CMS

Webiny’s Advanced Search Filter Builder enables users to effortlessly create complex search queries without depending on developer assistance. Users can create custom search queries based on model-defined fields that are one of the following types: boolean, datetime, number, or text. It supports grouping conditions and defining relationships between individual conditions or groups, thereby enhancing search accuracy and efficiency. In this tutorial, we will learn how to use advanced search filter.

Watch unedited video hereexternal link

Step 1:
anchor

  1. Make the following content entries in the Product content model:

    FolderProduct TitleProduct Description
    Home > ApparelsMen’s Black Half-sleeve T-shirtProduct: T-shirt; For: Men, Color: Black, Size: S, Type: Half-sleeve
    Home > ApparelsMen’s Red Half-sleeve T-shirtProduct: T-shirt; For: Men, Color: Red, Size: M, Type: Half-sleeve
    Home > ApparelsMen’s Black Full-sleeve T-shirtProduct: T-shirt; For: Men, Color: Black, Size: L, Type: Full-sleeve
    Home > ApparelsMen’s Red Full-sleeve T-shirtProduct: T-shirt; For: Men, Color: Red, Size: XL, Type: Full-sleeve
    Half SleeveFull Sleeve
    Men's Black Half-sleeve T-shirtMen's Black Half-sleeve T-shirt
    (click to enlarge)
    Men's Black Full-sleeve T-shirtMen's Black Full-sleeve T-shirt
    (click to enlarge)
    Men's Red Half-sleeve T-shirtMen's Red Half-sleeve T-shirt
    (click to enlarge)
    Men's Red Full-sleeve T-shirtMen's Red Full-sleeve T-shirt
    (click to enlarge)

    If you are not familiar with how to create a content entry, please follow the Create Content Entry tutorial.

Step 2:
anchor

  1. From the Side Menu, click Headless CMS > UNGROUPED > Product.

    ✔️ The Product content entries’ screen opens.

  2. Click the FILTER icon (🍸) in front of the SEARCH box.

  3. Click ADVANCED SEARCH FILTER.

    ✔️ The Advanced search filter screen opens.

  4. Click CREATE NEW.

    ✔️ The Advanced search filter builder screen opens.

  5. Under Filter group #1, in the Field dropdown, select Product Title.

  6. In the Condition dropdown, click contains.

  7. In the Value textbox, type Red.

  8. Click APPLY FILTER.

    ✔️ The entries Men’s Red Full-sleeve T-shirt and Men’s Red Half-sleeve T-shirt display in search results.

    Note: You can save a filter for later use by clicking SAVE FILTER.

Step 3:
anchor

  1. Follow Steps 1 to 7 of the previous step again.

    Note: The Match all conditions toggle button is ON by default. It means it will return the entries that meet all the given conditions. If it is set to OFF, it will return the entries that meet either of the given conditions.

  2. Click ADD NEW CONDITION icon (➕).

  3. In the Field dropdown, select Product Description.

  4. In the Condition dropdown, click contains.

  5. In the Value textbox, type Full.

  6. Click APPLY FILTER.

    ✔️ The entry Men’s Red Full-sleeve T-shirt displays in search results.

Note: You can add multiple conditions inside a Filter Group. You can also add multiple Filter Groups in a Search Query.
